78613/16C

Active

Murata Power Solutions Inc.

PULSE TRANSFORMER, LOW PROFILE, 1CT:1, 4 MH, 0.88 OHM, 28 VΜS, 1 KV, 78613/16C SERIES

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Technical Data Sheet EN +1

78613/16C

Active

Murata Power Solutions Inc.

PULSE TRANSFORMER, LOW PROFILE, 1CT:1, 4 MH, 0.88 OHM, 28 VΜS, 1 KV, 78613/16C SERIES

Deep-Dive with AI

DocumentsDatasheet Technical Data Sheet EN +1

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	78613/16C

ET (Volt-Time)	28 VµS
Height - Seated (Max)	6.35 mm
Height - Seated (Max) [Max]	0.25 in
Inductance	4 mH
Mounting Type	Through Hole
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	0 °C
Size / Dimension [x]	9.52 mm
Size / Dimension [x]	0.375 in
Size / Dimension [y]	0.354 in
Size / Dimension [y]	9 mm
Transformer Type	General Purpose
Turns Ratio - Primary:Secondary	1CT:1

78613 Series

Part	Transformer Type	ET (Volt-Time)	Turns Ratio - Primary:Secondary	Mounting Type	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Height - Seated (Max)	Height - Seated (Max) [Max]	Operating Temperature [Max]	Inductance	ET (Volt-Time) [custom]
Murata Power Solutions Inc. 78613/16C	General Purpose	28 VµS	1CT:1	Through Hole	9.52 mm	0.354 in	0.375 in	9 mm	6.35 mm	0.25 in	70 °C	4 mH
Murata Power Solutions Inc. 78613/1MC	General Purpose	20 VµS	1CT:1	Surface Mount	9.52 mm	0.354 in	0.375 in	9 mm	6.35 mm	0.25 in	70 °C	2 mH
Murata Power Solutions Inc. 78613/9C	General Purpose	56 VµS	1CT:1	Through Hole	9.52 mm	0.354 in	0.375 in	9 mm	6.35 mm	0.25 in	70 °C	10 mH
Murata Power Solutions Inc. 78613/1MC-R	General Purpose	20 VµS	1CT:1	Surface Mount	9.52 mm	0.354 in	0.375 in	9 mm	6.35 mm	0.25 in	70 °C	2 mH
Murata Power Solutions Inc. 78613/9MC	General Purpose	56 VµS	1CT:1	Surface Mount	9.52 mm	0.354 in	0.375 in	9 mm	6.35 mm	0.25 in	70 °C	10 mH
Murata Power Solutions Inc. 78613/3C	General Purpose	6 VµS	1CT:1	Through Hole	9.52 mm	0.354 in	0.375 in	9 mm	6.35 mm	0.25 in	70 °C	200 µH
Murata Power Solutions Inc. 78613/8JC	General Purpose	15 VµS	1CT:1	Surface Mount	9.52 mm	0.354 in	0.375 in	9 mm	6.35 mm	0.25 in	70 °C	980 µH
Murata Power Solutions Inc. 78613/1JC-R	General Purpose	20 VµS	1CT:1	Surface Mount	9.52 mm	0.354 in	0.375 in	9 mm	6.35 mm	0.25 in	70 °C	2 mH
Murata Power Solutions Inc. 78613/1JC	General Purpose	20 VµS	1CT:1	Surface Mount	9.52 mm	0.354 in	0.375 in	9 mm	6.35 mm	0.25 in	70 °C	2 mH
Murata Power Solutions Inc. 78613/2C	General Purpose		1CT:1	Through Hole	9.52 mm	0.354 in	0.375 in	9 mm	6.35 mm	0.25 in	70 °C	500 µH	10 VµS

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 1.57
		10	$ 1.55
		25	$ 1.53
		50	$ 1.50
		100	$ 1.42
		250	$ 1.32
		500	$ 1.24
		1000	$ 1.16
Newark	Each	50	$ 1.65
		100	$ 1.57
		250	$ 1.47

Description

General part information

78613 Series

4mH General Purpose Pulse Transformer 1CT:1 Through Hole
