12SX1-T

Active

Honeywell Sensing and Productivity Solutions

SWITCH SNAP ACTION SPDT 1A 125V

Search across all available documentation for this part.

Active

Honeywell Sensing and Productivity Solutions

SWITCH SNAP ACTION SPDT 1A 125V

Technical Specifications

Parameters and characteristics for this part

Part	Operating Force [Max]	Operating Force [Min]	Circuit	Actuator Type	Voltage Rating - AC	Switch Function	Mechanical Life	Voltage Rating - DC	Operating Position	Operating Position	Mounting Type	Overtravel	Overtravel	Release Force	Operating Temperature [Min]	Operating Temperature [Max]	Differential Travel	Differential Travel	Termination Style	Pretravel	Pretravel	Operating Force
Honeywell Sensing and Productivity Solutions 12SX3-T	141 gf	71 gf	SPDT	Round (Pin Plunger)	125 V	On-Mom	10000000 Cycles	28 V	8.13 mm	0.32 in	Chassis Mount	0.004 in	0.1 mm	28 gf	-55 °C	125 °C	0.025 mm	0.001 in	Solder Turret	0.02 in	0.5 mm
Honeywell Sensing and Productivity Solutions 12SX1-T			SPDT	Round (Pin Plunger)	125 V	On-Mom	10000000 Cycles	30 V	8.13 mm	0.32 in	Chassis Mount	0.004 in	0.1 mm	28 gf	-55 °C	125 °C			Solder Turret	0.02 in	0.5 mm	141 gf
Honeywell Sensing and Productivity Solutions 12SX9-T			SPDT	Round (Pin Plunger)	125 V	On-Mom	10000000 Cycles	30 V	8.13 mm	0.32 in	Chassis Mount	0.01 in	0.25 mm	28 gf	-55 °C	125 °C			Solder Turret	0.02 in	0.5 mm	141 gf
Honeywell Sensing and Productivity Solutions 12SX14-T	141 gf	71 gf	SPDT	Round (Pin Plunger)	125 V	On-Mom	10000000 Cycles	30 V	8.13 mm	0.32 in	Chassis Mount	0.004 in	0.1 mm	28 gf	-55 °C	125 °C	0.05 mm	0.002 in	Solder Turret	0.02 in	0.5 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Switch SPDT Chassis Mount
