CLU701-0303C4-403M2K1
ActiveCitizen Finedevice Co Ltd
LED COB CLU701 NEUT WH SQ 4000K
Deep-Dive with AI
Search across all available documentation for this part.
CLU701-0303C4-403M2K1
ActiveCitizen Finedevice Co Ltd
LED COB CLU701 NEUT WH SQ 4000K
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | CLU701-0303C4-403M2K1 |
|---|---|
| CCT (K) | 4000 K |
| Color | Neutral, White |
| Configuration | Square |
| CRI (Color Rendering Index) | 80 |
| Current - Max [Max] | 690 mA |
| Current - Test | 525 mA |
| Lens Type | Flat |
| Light Emitting Surface (LES) [diameter] | 6 mm Dia |
| Lumens/Watt @ Current - Test | 127 lm/W |
| Luminous Flux @ Current/Temperature | 625 lm |
| Temperature - Test | 85 °C |
| Type | Chip On Board (COB) |
| Voltage - Forward (Vf) (Typ) | 9.4 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 4.67 | |
| 10 | $ 3.21 | |||
| 80 | $ 2.52 | |||
| 440 | $ 2.19 | |||
| 945 | $ 2.08 | |||
| 2000 | $ 2.00 | |||
| 4900 | $ 1.94 | |||
Description
General part information
CLU701 Series
LED Lighting COBs Engines Modules Chip On Board (COB) CLU701 White, Neutral Square
Documents
Technical documentation and resources
No documents available
