073I,GY

Active

Serpac

BOX ABS GRAY 6.88"L X 4.88"W

Search across all available documentation for this part.

Active

Serpac

BOX ABS GRAY 6.88"L X 4.88"W

Technical Specifications

Parameters and characteristics for this part

Specification	073I,GY

Area (L x W)	33.6 in²
Area (L x W)	217 cm²
Color	Gray
Container Type	Box
Features	PCB Supports
Height [z]	48.26 mm
Height [z]	1.9 in
Material	Plastic, ABS
Material Flammability Rating	UL94 HB
Ratings	IP40, NEMA 1
Size / Dimension [x]	174.75 mm
Size / Dimension [x]	6.88 in
Size / Dimension [y]	123.95 mm
Size / Dimension [y]	4.88 in
Thickness	2.54 mm
Thickness	0.1 in
Weight	200.03 g
Weight	0.441 lb

Part	Color	Weight	Weight	Ratings	Material	Thickness	Thickness	Material Flammability Rating	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Container Type	Height [z]	Height [z]	Area (L x W)	Area (L x W)	Features	Area (L x W) [custom]	Area (L x W) [custom]	Design
Serpac 073I,GY	Gray	200.03 g	0.441 lb	IP40 NEMA 1	Plastic ABS	2.54 mm	0.1 in	UL94 HB	123.95 mm	174.75 mm	4.88 in	6.88 in	Box	48.26 mm	1.9 in	33.6 in²	217 cm²	PCB Supports
Serpac 073I,BK	Black	200.03 g	0.441 lb	IP40 NEMA 1	Plastic ABS	2.54 mm	0.1 in	UL94 HB	123.95 mm	174.75 mm	4.88 in	6.88 in	Box	48.26 mm	1.9 in			PCB Supports	217 cm˛	33.6 in˛	Cover Included Hand Held

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Box Plastic, ABS Gray 6.880" L x 4.880" W (174.75mm x 123.95mm) X 1.900" (48.26mm)

Technical documentation and resources
