40HS24N102JC

Active

KEMET

CAP CER 1000PF 4KV NP0 RADIAL

Search across all available documentation for this part.

Active

KEMET

CAP CER 1000PF 4KV NP0 RADIAL

Technical Specifications

Parameters and characteristics for this part

Part	Package / Case	Temperature Coefficient	Features	Lead Spacing	Lead Spacing	Mounting Type	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Lead Style	Tolerance	Applications	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Capacitance	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Rated	Voltage - Rated
KEMET 40HS24N102JC	Radial	C0G NP0	High Voltage	12.06 mm	0.475 in	Through Hole	12.7 mm	0.5 in	Straight	5 %	General Purpose	0.57 in	14.48 mm	0.271 "	6.89 mm	0.001 µF	-55 °C	125 °C	4 kV	4000 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

1000 pF ±5% 4000V (4kV) Ceramic Capacitor C0G, NP0 Radial

Technical documentation and resources
