UMPS-04-07.5-L-V-S-W-TR

Active

Samtec Inc.

CONN RCPT 4POS 2.00MM SMD SLDR

Search across all available documentation for this part.

Active

Samtec Inc.

CONN RCPT 4POS 2.00MM SMD SLDR

Technical Specifications

Parameters and characteristics for this part

Specification	UMPS-04-07.5-L-V-S-W-TR

Color	Black
Connector Type	Receptacle, Female Blade Sockets
Contact Finish	Gold
Contact Finish Thickness	10 Áin
Contact Finish Thickness	0.25 Ám
Contact Material	Copper Alloy
Features	Solder Retention
Material - Insulation	Liquid Crystal Polymer (LCP)
Mounting Type	Surface Mount
Number of Positions	4
Number of Rows	1
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Pitch [x]	0.079 in
Pitch [x]	2 mm
Termination	Solder
Voltage Rating	650 V

Part	Mounting Type	Contact Material	Features	Contact Finish	Contact Finish Thickness	Contact Finish Thickness	Color	Operating Temperature [Min]	Operating Temperature [Max]	Material - Insulation	Number of Positions	Pitch [x]	Pitch [x]	Termination	Connector Type	Number of Rows	Voltage Rating
Samtec Inc. UMPS-04-03.5-L-V-S-W-TR	Surface Mount	Copper Alloy	Solder Retention	Gold	10 Áin	0.25 Ám	Black	-55 °C	125 °C	Liquid Crystal Polymer (LCP)	4	0.079 in	2 mm	Solder	Receptacle Female Blade Sockets	1	650 V
Samtec Inc. UMPS-04-05.5-G-V-S-W-TR	Surface Mount	Copper Alloy	Pick and Place Solder Retention	Gold	10 Áin	0.25 Ám	Black	-55 °C	125 °C	Liquid Crystal Polymer (LCP)	4	0.079 in	2 mm	Solder	Receptacle Female Blade Sockets	1	650 V
Samtec Inc. UMPS-04-03.5-G-V-S-W-FR	Surface Mount	Copper Alloy	Pick and Place Solder Retention	Gold	10 Áin	0.25 Ám	Black	-55 °C	125 °C	Liquid Crystal Polymer (LCP)	4	0.079 in	2 mm	Solder	Receptacle Female Blade Sockets	1	650 V
Samtec Inc. UMPS-04-07.5-L-V-S-W-TR	Surface Mount	Copper Alloy	Solder Retention	Gold	10 Áin	0.25 Ám	Black	-55 °C	125 °C	Liquid Crystal Polymer (LCP)	4	0.079 in	2 mm	Solder	Receptacle Female Blade Sockets	1	650 V
Samtec Inc. UMPS-04-05.5-L-V-S-W-TR	Surface Mount	Copper Alloy	Solder Retention	Gold	10 Áin	0.25 Ám	Black	-55 °C	125 °C	Liquid Crystal Polymer (LCP)	4	0.079 in	2 mm	Solder	Receptacle Female Blade Sockets	1	650 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

4 Position Receptacle, Female Blade Sockets Connector Solder 0.079" (2.00mm) Surface Mount
