CP3502P1V00-NH
ActiveCvilux USA
2 POS 3.00MM(.118) DUAL ROWS VER
Deep-Dive with AI
Search across all available documentation for this part.
CP3502P1V00-NH
ActiveCvilux USA
2 POS 3.00MM(.118) DUAL ROWS VER
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | CP3502P1V00-NH |
|---|---|
| Connector Type | Header |
| Contact Finish - Post | Tin |
| Contact Length - Post | 3.2 mm |
| Contact Length - Post [x] | 0.126 in |
| Contact Material | Brass |
| Contact Shape | Square |
| Contact Type | Male Pin |
| Current Rating (Amps) | 7 A |
| Fastening Type | Locking Ramp |
| Features | Board Guide |
| Insulation Color | Black |
| Insulation Height [z] | 9.91 mm |
| Insulation Height [z] | 0.39 in |
| Insulation Material | Thermoplastic |
| Mounting Type | Through Hole |
| Number of Positions | 2 |
| Number of Positions Loaded | All |
| Number of Rows | 2 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Row Spacing - Mating | 3 mm |
| Row Spacing - Mating | 0.118 in |
| Shrouding | Shrouded - 4 Wall |
| Style | Board to Cable/Wire |
| Termination | Kinked Pin, Solder |
| Voltage Rating | 600 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 0.37 | |
| 10 | $ 0.32 | |||
| 120 | $ 0.25 | |||
| 480 | $ 0.21 | |||
| 960 | $ 0.18 | |||
| 4920 | $ 0.15 | |||
| 10080 | $ 0.14 | |||
Description
General part information
CP3502P1 Series
Connector Header Through Hole 2 position
Documents
Technical documentation and resources
No documents available
