PKV5325PI

Active

Flex Power Modules

DC DC CONVERTER +/-15V 3W

Search across all available documentation for this part.

Active

Flex Power Modules

DC DC CONVERTER +/-15V 3W

Technical Specifications

Parameters and characteristics for this part

Part	Operating Temperature [Min]	Operating Temperature [Max]	Current - Output (Max)	Current - Output (Max)	Voltage - Input (Max) [Max]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Number of Outputs	Voltage - Isolation	Standard Number	Type	Package / Case	Mounting Type	Applications	Voltage - Input (Min) [Min]	Approval Agency	Voltage - Output 1	Power (Watts)	Voltage - Output 2	Current - Output (Max)
Flex Power Modules PKV5325PI	-40 °C	95 °C	100 mA	100 mA	72 V	10.7 mm	1.25 "	0.8 in	20.3 mm	31.8 mm	0.42 in	2	1.5 kV	62368-1	Isolated Module	24-DIP Module 10 Leads	Through Hole	ITE (Commercial)	18 V	CB CSA IEC TUV UL	15 V	3 W	-15 V
Flex Power Modules PKV5321PI	-40 °C	95 °C	125 mA		72 V	10.7 mm	1.25 "	0.8 in	20.3 mm	31.8 mm	0.42 in	2	1.5 kV	62368-1	Isolated Module	24-DIP Module 10 Leads	Through Hole	ITE (Commercial)	18 V	CB CSA IEC TUV UL	12 V	3 W	-12 V	125 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	300	$ 25.05

General part information

Isolated Module DC DC Converter 2 Output 15V -15V 100mA, 100mA 18V - 72V Input
