2017-42-SMC-RPLF

Active

Bourns Inc.

GDT 420V 10KA 2 POLE SMD VERT

Search across all available documentation for this part.

Active

Bourns Inc.

GDT 420V 10KA 2 POLE SMD VERT

Technical Specifications

Parameters and characteristics for this part

Specification	2017-42-SMC-RPLF

Fail Short	False
Impulse Discharge Current (8/20µs)	10000 A
Impulse Discharge Current (8/20µs)	10 kA
Mounting Type	Surface Mount Vertical
Number of Poles	2
Package / Case	8 mm
Package / Case	Disc
Tolerance	20 %
Voltage - DC Spark Over (Nom)	420 V

Part	Tolerance	Voltage - DC Spark Over (Nom)	Number of Poles	Package / Case	Package / Case	Impulse Discharge Current (8/20µs)	Impulse Discharge Current (8/20µs)	Mounting Type
Bourns Inc. 2017-09-SMH-RPLF	20 %	90 V	2	8 mm	Disc	10000 A	10 kA	Surface Mount Horizontal
Bourns Inc. 2017-50-SMH-RPLF	20 %	500 V	2	8 mm	Disc	10000 A	10 kA	Surface Mount Horizontal
Bourns Inc. 2017-15-SMH-RPLF	20 %	150 V	2	8 mm	Disc	10000 A	10 kA	Surface Mount Horizontal
Bourns Inc. 2017-42-SMC-RPLF	20 %	420 V	2	8 mm	Disc	10000 A	10 kA	Surface Mount Vertical

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Cut Tape (CT)	1	$ 3.12
	Digi-Reel®	1	$ 3.12
	Tape & Reel (TR)	1000	$ 1.41

General part information

Gas Discharge Tube 420 V 10000A (10kA) ±20% 2 Pole Surface Mount Vertical

Technical documentation and resources
