ATS-CP-1002-DIY
ActiveAdvanced Thermal Solutions Inc.
LIQUID COLD PLATES, LIQUID COOLING & HEAT PIPES MINI CHANNEL COLD PLATE, IGBT, NO FINISH, 0.008C/W @1GPM, NO HOLE, 162X136X20MM
Deep-Dive with AI
Search across all available documentation for this part.
ATS-CP-1002-DIY
ActiveAdvanced Thermal Solutions Inc.
LIQUID COLD PLATES, LIQUID COOLING & HEAT PIPES MINI CHANNEL COLD PLATE, IGBT, NO FINISH, 0.008C/W @1GPM, NO HOLE, 162X136X20MM
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | ATS-CP-1002-DIY |
|---|---|
| Dimensions - Overall [x] | 6.38 " |
| Dimensions - Overall [x] | 162 mm |
| Dimensions - Overall [y] | 5.35 " |
| Dimensions - Overall [y] | 136 mm |
| Dimensions - Overall [z] | 0.79 " |
| Dimensions - Overall [z] | 20 mm |
| Flow Rate | 4 LPM |
| Flow Rate | 1.06 GPM |
| Power - Cooling | 1000 W |
| Product Type | Passive, Cold Plate |
| Thermal Resistance @ GPM | 0.007 °C/W |
| Weight | 2.4 lbs |
| Weight | 1.1 kg |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
IGBT CP DIY Series
Liquid Cold Plates, Liquid Cooling & Heat Pipes Mini Channel Cold Plate, IGBT, No Finish, 0.005C/W @1GPM, No Hole, 198x147x20mm
