3RP20052AP30

Active

Siemens

RELAY TIME DELAY 100SEC 3A 250V

Search across all available documentation for this part.

Active

Siemens

RELAY TIME DELAY 100SEC 3A 250V

Technical Specifications

Parameters and characteristics for this part

Specification	3RP20052AP30

Contact Rating @ Voltage	250 VAC, 3 A
Delay Time [Max]	100 Sec
Delay Time [Min]	0.05 Sec
Function	Programmable (Multi-Function)
Mounting Type	Chassis Mount, DIN Rail
Relay Type	Mechanical Relay
Termination Style	Spring Terminal
Timing Adjustment Method	Screwdriver Slot
Timing Initiate Method	Input Voltage
Voltage - Supply	24 VAC
Voltage - Supply [Max]	240 VAC
Voltage - Supply [Min]	200 VAC

Part	Timing Initiate Method	Delay Time [Min]	Delay Time [Max]	Relay Type	Contact Rating @ Voltage	Function	Voltage - Supply [Max]	Voltage - Supply	Voltage - Supply [Min]	Mounting Type	Termination Style	Timing Adjustment Method	Circuit
Siemens 3RP20052AP30	Input Voltage	0.05 Sec	100 Sec	Mechanical Relay	3 A 250 VAC	Programmable (Multi-Function)	240 VAC	24 VAC	200 VAC	Chassis Mount DIN Rail	Spring Terminal	Screwdriver Slot
Siemens 3RP20051BW30	Input Voltage	0.05 Sec	100 Sec	Mechanical Relay	3 A 250 VAC	Programmable (Multi-Function)	240 VAC		24 VAC	Chassis Mount DIN Rail	Screw Terminal	Screwdriver Slot	DPDT (2 Form C)
Siemens 3RP20051AP30	Input Voltage	0.05 Sec	100 Sec	Mechanical Relay	3 A 250 VAC	Programmable (Multi-Function)	240 VAC	24 VAC	200 VAC	Chassis Mount DIN Rail	Screw Terminal	Screwdriver Slot
Siemens 3RP20052BW30	Input Voltage	0.05 Sec	100 Sec	Mechanical Relay	3 A 250 VAC	Programmable (Multi-Function)	240 VAC		24 VAC	Chassis Mount DIN Rail	Spring Terminal	Screwdriver Slot	DPDT (2 Form C)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 218.00

General part information

Programmable (Multi-Function) Time Delay Relay SPDT (1 Form C) 0.05 Sec ~ 100 Sec Delay 3A @ 250VAC Chassis Mount, DIN Rail
