XA6SLX25-3CSG324Q

Active

AMD

IC FPGA 226 I/O 324CSBGA

Search across all available documentation for this part.

Active

AMD

IC FPGA 226 I/O 324CSBGA

Technical Specifications

Parameters and characteristics for this part

Specification	XA6SLX25-3CSG324Q

Grade	Automotive
Mounting Type	Surface Mount
Number of I/O	226
Number of LABs/CLBs	1879
Number of Logic Elements/Cells	24051
Operating Temperature [Max]	125 ¯C
Operating Temperature [Min]	-40 °C
Package / Case	324-LFBGA, CSPBGA
Qualification	AEC-Q100
Supplier Device Package	324-CSPBGA (15x15)
Total RAM Bits	958464 bits

Part	Number of Logic Elements/Cells	Grade	Supplier Device Package	Qualification	Package / Case	Total RAM Bits	Number of I/O	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Number of LABs/CLBs
AMD XA6SLX25-2CSG324I	24051	Automotive	324-CSPBGA (15x15)	AEC-Q100	324-LFBGA CSPBGA	958464 bits	226	Surface Mount	100 °C	-40 C	1879
AMD XA6SLX25-3FTG256Q	24051	Automotive	256-FTBGA (17x17)	AEC-Q100	256-LBGA	958464 bits	186	Surface Mount	125 ¯C	-40 °C	1879
AMD XA6SLX25-3CSG324Q	24051	Automotive	324-CSPBGA (15x15)	AEC-Q100	324-LFBGA CSPBGA	958464 bits	226	Surface Mount	125 ¯C	-40 °C	1879
AMD XA6SLX25T-3FGG484Q	24051	Automotive	484-FBGA (23x23)	AEC-Q100	484-BBGA	958464 bits	250	Surface Mount	125 ¯C	-40 °C	1879

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	3	$ 123.34

General part information

Spartan®-6 LX XA Field Programmable Gate Array (FPGA) IC 226 958464 24051 324-LFBGA, CSPBGA

Technical documentation and resources

No documents available
