SCWN06A-03

Active

MEAN WELL USA Inc.

DC DC CONVERTER 3.3V 4W

Search across all available documentation for this part.

Active

MEAN WELL USA Inc.

DC DC CONVERTER 3.3V 4W

Technical Specifications

Parameters and characteristics for this part

Part	Type	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Isolation	Package / Case	Mounting Type	Current - Output (Max) [Max]	Voltage - Output 1	Power (Watts)	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Number of Outputs	Applications	Voltage - Input (Min) [Min]	Features	Voltage - Input (Max) [Max]	Approval Agency	Efficiency
MEAN WELL USA Inc. SCWN06A-03	Isolated Module	-40 °C	90 °C	3000 V	24-DIP Module 8 Leads	Through Hole	1.2 A	3.3 V	4 W	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm	1	ITE (Commercial)	9 V	OCP SCP UVLO	18 V	CE EAC	77 %
MEAN WELL USA Inc. SCWN06C-05	Isolated Module	-40 °C	90 °C	3000 V	24-DIP Module 8 Leads	Through Hole	1 A	5 V	5 W	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm	1	ITE (Commercial)	36 V	OCP SCP UVLO	72 V	CE EAC	83 %
MEAN WELL USA Inc. SCWN06A-05	Isolated Module	-40 °C	90 °C	3000 V	24-DIP Module 8 Leads	Through Hole	1 A	5 V	5 W	31.8 mm	0.4 "	1.25 "	10.2 mm	0.8 in	20.3 mm	1	ITE (Commercial)	9 V	OCP SCP UVLO	18 V	CE EAC	81 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 1 Output 3.3V 1.2A 9V - 18V Input
