M13176 SL001

Active

ALPHA WIRE

MULTI-PAIR 12COND 18AWG

Search across all available documentation for this part.

Active

ALPHA WIRE

MULTI-PAIR 12COND 18AWG

Technical Specifications

Parameters and characteristics for this part

Specification	M13176 SL001

Cable Type	Multi-Pair
Conductor Insulation	Polyethylene (PE)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	16
Conductor Strand [custom]	30 AWG
Features	Drain Wire
Jacket (Insulation) Diameter [diameter]	0.541 in
Jacket (Insulation) Diameter [diameter]	13.74 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	1.194 mm
Jacket (Insulation) Thickness	0.047 in
Jacket Color	Slate
Length	1000 ft
Length	304.8 m
Number of Conductors	12
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-20 C
Ratings	UL Style 2919
Shield Coverage	100 %
Shield Material	Aluminum
Shield Type	Foil
Voltage	300 V
Wire Gauge	18 AWG

Part	Conductor Insulation	Length	Length	Features	Voltage	Ratings	Jacket Color	Conductor Material	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Material	Shield Type	Wire Gauge	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Number of Conductors	Operating Temperature [Min]	Operating Temperature [Max]	Shield Material	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Shield Coverage	Cable Type
ALPHA WIRE M13176 SL001	Polyethylene (PE)	1000 ft	304.8 m	Drain Wire	300 V	UL Style 2919	Slate	Copper Tinned	16	30 AWG	Poly-Vinyl Chloride (PVC)	Foil	18 AWG	0.541 in	13.74 mm	12	-20 C	80 C	Aluminum	1.194 mm	0.047 in	100 %	Multi-Pair

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 3.12

General part information

12 (6 Pair Twisted) Conductor Multi-Pair Cable Slate 18 AWG Foil 1000.0' (304.8m)
