QS54FCT541TQ

Obsolete

Quality Semiconductor

IC ADDRESS DRIVER 5V 128KX36 4NS

Search across all available documentation for this part.

Obsolete

Quality Semiconductor

IC ADDRESS DRIVER 5V 128KX36 4NS

Technical Specifications

Parameters and characteristics for this part

Specification	QS54FCT541TQ

Current - Output High, Low [custom]	12 mA
Current - Output High, Low [custom]	48 mA
Logic Type	Address Driver
Mounting Type	Surface Mount
Number of Bits per Element	8
Number of Elements	1
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Output Type	3-State

Part	Logic Type	Operating Temperature [Min]	Operating Temperature [Max]	Output Type	Number of Elements	Number of Bits per Element	Current - Output High, Low [custom]	Current - Output High, Low [custom]	Mounting Type
Quality Semiconductor QS54FCT541TQ	Address Driver	-55 °C	125 °C	3-State	1	8	12 mA	48 mA	Surface Mount
Quality Semiconductor QS54FCT541ATQ

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	592	$ 0.51

General part information

Address Driver 1 Element 8 Bit per Element 3-State Output

Technical documentation and resources

No documents available
