09340062701

Active

HARTING Technology Group

HEAVY DUTY CONNECTOR, 6+PE SIGNAL, 2 ADDITIONAL CONTACTS, HIGH VOLTAGE, HAN HV E SERIES, INSERT

Search across all available documentation for this part.

Active

HARTING Technology Group

HEAVY DUTY CONNECTOR, 6+PE SIGNAL, 2 ADDITIONAL CONTACTS, HIGH VOLTAGE, HAN HV E SERIES, INSERT

Technical Specifications

Parameters and characteristics for this part

Specification	09340062701

Color	Gray
Contact Finish	Silver
Contact Material	Copper Alloy
Current Rating (Amps)	16 A
Gender	Female
Housing Material	Polycarbonate (PC)
Material Flammability Rating	UL94 V-0
Number of Positions [custom]	Ground
Number of Positions [custom]	6
Number of Positions [custom]	2
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Size	16 B
Termination Style	Screw
Voltage Rating	830 V

Part	Material Flammability Rating	Number of Positions [custom]	Number of Positions [custom]	Number of Positions [custom]	Contact Type	Voltage Rating	Size	Housing Material	Termination Style	Gender	Contact Material	Contact Finish	Operating Temperature [Max]	Operating Temperature [Min]	Current Rating (Amps)	Color	Connector Type
HARTING Technology Group 09340062716	UL94 V-0	Ground	6	2	Han®	830 V	16 B	Polycarbonate (PC)	Push In	Female	Copper Alloy	Silver	125 °C	-40 °C	16 A	Gray
HARTING Technology Group 09340062702	UL94 V-0	Ground	6	2	Han®	830 V	16 B	Polycarbonate (PC)	Crimp	Female			125 °C	-40 °C	16 A	Gray	Insert without Contacts
HARTING Technology Group 09340062701	UL94 V-0	Ground	6	2		830 V	16 B	Polycarbonate (PC)	Screw	Female	Copper Alloy	Silver	125 °C	-40 °C	16 A	Gray

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Female Insert Gray 6+2+Ground Position Screw
