UX4S0

Active

EXCELSYS / Advanced Energy

CONFIG PWR CHASSIS 600W 4 SLOT

Search across all available documentation for this part.

Active

EXCELSYS / Advanced Energy

CONFIG PWR CHASSIS 600W 4 SLOT

Technical Specifications

Parameters and characteristics for this part

Specification	UX4S0

Approval Agency	CE
Efficiency	91 %
Features	Ruggedized, Fan Fail, Reverse Fan, Temperature Alarm, Conformal Coating
Height [z]	40.4 mm
Height [z]	1.59 in
Number of Positions	4
Power (Watts)	600 W
Size / Dimension [x]	10.24 "
Size / Dimension [x]	260 mm
Size / Dimension [y]	89 mm
Size / Dimension [y]	3.5 in
Type	Medical
Voltage - Input [Max]	264 VAC, 380 VDC
Voltage - Input [Min]	120 VDC, 85 VAC
Voltage - Isolation	4000 V

Modular Power Supplies 4-slot, 600W powerPac with flying lead, 3-wire input

Part	Efficiency	Type	Features	Number of Positions	Approval Agency	Power (Watts)	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Height [z]	Height [z]	Voltage - Isolation	Voltage - Input [Max]	Voltage - Input [Min]
EXCELSYS / Advanced Energy UX4-D0	90 %	Medical	Fan Fail Temperature Alarm	4	CE	600 W	10.24 "	260 mm	89 mm	3.5 in	40.4 mm	1.59 in	4000 V
EXCELSYS / Advanced Energy UX4S0	91 %	Medical	Conformal Coating Fan Fail Reverse Fan Ruggedized Temperature Alarm	4	CE	600 W	10.24 "	260 mm	89 mm	3.5 in	40.4 mm	1.59 in	4000 V	264 VAC 380 VDC	85 VAC 120 VDC
EXCELSYS / Advanced Energy UX4C04	90 %	Medical	Fan Fail Temperature Alarm	4	CE cURus	600 W	10.24 "	260 mm	89 mm	3.5 in	40.4 mm	1.59 in	4000 V
EXCELSYS / Advanced Energy UX4-02	90 %	Medical	Fan Fail Temperature Alarm	4	CE cURus	600 W	10.24 "	260 mm	89 mm	3.5 in	40.4 mm	1.59 in	4000 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Modular Power Supplies 4-slot, 600W powerPac with flying lead, 3-wire input
