KBPC800

Active

Diotec Semiconductor

BRIDGE RECT 1PHASE 50V 5A KBPC8

Search across all available documentation for this part.

Active

Diotec Semiconductor

BRIDGE RECT 1PHASE 50V 5A KBPC8

Technical Specifications

Parameters and characteristics for this part

Specification	KBPC800

Current - Average Rectified (Io)	5 A
Current - Reverse Leakage @ Vr	5 µA
Diode Type	Single Phase
Mounting Type	Through Hole
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-50 °C
Package / Case	4-Square, KBPC-6, 4-Square, KBPC-8
Supplier Device Package	KBPC8
Technology	Standard
Voltage - Forward (Vf) (Max) @ If	1.2 V
Voltage - Peak Reverse (Max) [Max]	50 V

Part	Mounting Type	Current - Average Rectified (Io)	Technology	Current - Reverse Leakage @ Vr	Package / Case	Voltage - Forward (Vf) (Max) @ If	Voltage - Peak Reverse (Max) [Max]	Supplier Device Package	Diode Type	Operating Temperature [Max]	Operating Temperature [Min]
Diotec Semiconductor KBPC810	Through Hole	5 A	Standard	5 µA	4-Square KBPC-8	1.2 V	1000 V	KBPC8	Single Phase	150 °C	-50 °C
Diotec Semiconductor KBPC806	Through Hole	5 A	Standard	5 µA	4-Square KBPC-8	1.2 V	600 V	KBPC8	Single Phase	150 °C	-50 °C
Diotec Semiconductor KBPC800	Through Hole	5 A	Standard	5 µA	4-Square KBPC-6 4-Square KBPC-8	1.2 V	50 V	KBPC8	Single Phase	150 °C	-50 °C
Diotec Semiconductor KBPC804	Through Hole	5 A	Standard	5 µA	4-Square KBPC-8	1.2 V	400 V	KBPC8	Single Phase	150 °C	-50 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Bridge Rectifier Single Phase Standard 50 V Through Hole KBPC8
