48.52.8.024.0060SPA
ActiveFinder Relays, Inc.
RELAY GEN PURPOSE DPDT 8A 24V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
48.52.8.024.0060SPA
ActiveFinder Relays, Inc.
RELAY GEN PURPOSE DPDT 8A 24V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 48.52.8.024.0060SPA |
|---|---|
| Coil Current | 46 mA |
| Coil Type | Non Latching |
| Coil Voltage | 24 VAC |
| Contact Form | DPDT (2 Form C) |
| Contact Material | Silver Nickel (AgNi) |
| Contact Rating (Current) | 8 A |
| Features | Varistor, Lighted Indicator |
| Load - Max Switching | 3200 VA |
| Mounting Type | DIN Rail |
| Must Operate Voltage | 19.2 VAC |
| Must Release Voltage | 4.8 VAC |
| Operate Time | 7 ms |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -40 °C |
| Relay Type | General Purpose |
| Release Time | 4 ms |
| Switching Voltage [Max] | 400 VAC |
| Termination Style | Screw Terminal |
48.52.8 Series
| Part | Operate Time | Must Release Voltage | Operating Temperature [Min] | Operating Temperature [Max] | Contact Form | Contact Material | Must Operate Voltage | Features | Contact Rating (Current) | Coil Voltage | Load - Max Switching | Termination Style | Relay Type | Switching Voltage [Max] | Release Time | Coil Current | Mounting Type | Coil Type | Coil Resistance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Finder Relays, Inc. | 7 ms | 4.8 VAC | -40 °C | 70 °C | DPDT (2 Form C) | Silver Nickel (AgNi) | 19.2 VAC | Lighted Indicator Varistor | 8 A | 24 VAC | 3200 VA | Screw Terminal | General Purpose | 400 VAC | 4 ms | 46 mA | DIN Rail | Non Latching | |
Finder Relays, Inc. | 7 ms | 46 VAC | -40 °C | 70 °C | DPDT (2 Form C) | Silver Nickel (AgNi) | 184 VAC | Lighted Indicator Varistor | 8 A | 230 VAC | 3200 VA | Screw Terminal | General Purpose | 400 VAC | 4 ms | 7 mA | DIN Rail | Non Latching | 32.9 kOhms |
Finder Relays, Inc. | 7 ms | 4.8 VAC | -40 °C | 70 °C | DPDT (2 Form C) | Silver Nickel (AgNi) | 19.2 VAC | Lighted Indicator Varistor | 8 A | 24 VAC | 3200 VA | Screw Terminal | General Purpose | 400 VAC | 4 ms | 46 mA | DIN Rail | Non Latching | 521.7 Ohms |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 19.93 | |
| 10 | $ 17.71 | |||
| 30 | $ 16.83 | |||
| 50 | $ 15.94 | |||
| 100 | $ 15.06 | |||
| 250 | $ 13.73 | |||
| 500 | $ 12.84 | |||
Description
General part information
48.52.8 Series
General Purpose Relay DPDT (2 Form C) 24VAC Coil DIN Rail
