TANGO47/2.5M/SMAM/SMAM/S/S/17
ActiveSiretta Ltd
4G/LTE MINI WHIP STYLE PANEL MOU
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TANGO47/2.5M/SMAM/SMAM/S/S/17 |
|---|---|
| Antenna Type | Module |
| Applications | GSM, 4G, GPS, 2G, 3G |
| Features | Cable |
| Features | 2.5 m |
| Frequency (Center/Band) | 1.575 GHz, 1.9 GHz, 850 MHz, 2.7 GHz, 900 MHz, 2.1 GHz, 1.8 GHz |
| Frequency Group | Wide Band |
| Gain | 3 dBi, 2 dBic |
| Height (Max) [Max] [z] | 16 mm |
| Height (Max) [Max] [z] | 0.63 in |
| Number of Bands | 7 |
| RF Family/Standard | Cellular, Navigation |
| Termination | SMA Male (2) |
| VSWR [Max] | 2 |
| VSWR [Min] | 1.5 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 46.35 | |
| 10 | $ 43.25 | |||
| 25 | $ 41.43 | |||
| 100 | $ 37.55 | |||
| 250 | $ 36.25 | |||
Description
General part information
TANGO47 Series
RF ANTENNA 2G, 3G, 4G, GPS, GSM Module SMA Male (2) Panel Mount
