9TN48P1H01
ActiveSanyo Denki America Inc.
FAN AXIAL 150X35MM 48VDC WIRE
Deep-Dive with AI
Search across all available documentation for this part.
9TN48P1H01
ActiveSanyo Denki America Inc.
FAN AXIAL 150X35MM 48VDC WIRE
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 9TN48P1H01 |
|---|---|
| Air Flow | 3.78 mł/min |
| Air Flow | 135 CFM |
| Approval Agency | CSA, TUV, UL |
| Bearing Type | Ball |
| Current Rating (Amps) | 320 mA |
| Fan Type | Tubeaxial |
| Features | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) |
| Lifetime @ Temp. | 40000 Hrs |
| Material - Blade | Plastic |
| Material - Frame | Aluminum |
| Noise | 59 dB(A) |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -20 °C |
| Operating Temperature [Min] | -20 C |
| Power (Watts) | 15.4 W |
| RPM | 3800 RPM |
| Size / Dimension [x] | 150 mm |
| Size / Dimension [y] | 150 mm |
| Static Pressure | 1.57 in H2O |
| Static Pressure | 391.1 Pa |
| Termination | 4 Wire Leads |
| Voltage - Rated [custom] | 48 VDC |
| Voltage Range [Max] | 55.2 VDC |
| Voltage Range [Min] | 36 VDC |
| Weight | 330.22 g |
| Weight | 0.728 lb |
| Width [y] | 35 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 66.74 | |
| 10 | $ 60.39 | |||
| 30 | $ 56.41 | |||
| 50 | $ 55.62 | |||
| 100 | $ 51.25 | |||
Description
General part information
9TN48 Series
Fan Tubeaxial 48VDC Square - 150mm L x 150mm H Ball 135.0 CFM (3.78mł/min) 4 Wire Leads
