C091 11S003 000 2

Active

Amphenol Tuchel Industrial

CONN RCPT HSNG MALE 3POS PNL MNT

Search across all available documentation for this part.

Active

Amphenol Tuchel Industrial

CONN RCPT HSNG MALE 3POS PNL MNT

Technical Specifications

Parameters and characteristics for this part

Specification	C091 11S003 000 2

Connector Type	Receptacle Housing
Contact Shape	Circular
Contact Size	1.5 mm
Contact Type	Crimp
Housing Color	Silver
Ingress Protection	IP69K, IP65, IP67
Insert Material	Thermoplastic
Material Flammability Rating	UL94 V-0
Mounting Feature	Flange
Note	Contacts Not Included
Operating Temperature [Max]	100 °C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Shell Finish	Nickel
Shell Material	Die Cast
Shell Size - Insert	M16-3
Shielding	Shielded
Type	For Male Pins

Part	Ingress Protection	Contact Size	Material Flammability Rating	Shell Material	Contact Type	Shell Size - Insert	Shell Finish	Contact Shape	Orientation	Type	Note	Shielding	Connector Type	Housing Color	Insert Material	Mounting Feature	Operating Temperature [Max]	Operating Temperature [Min]
Amphenol Tuchel Industrial C091 11S003 000 2	IP65 IP67 IP69K	1.5 mm	UL94 V-0	Die Cast	Crimp	M16-3	Nickel	Circular	Keyed	For Male Pins	Contacts Not Included	Shielded	Receptacle Housing	Silver	Thermoplastic	Flange	100 °C	-40 °C

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	100	$ 7.17

General part information

3 Position Circular Connector Receptacle Housing Panel Mount
