242R7C

Active

Murata Power Solutions Inc.

FIXED IND 2.7UH 2.6A 39 MOHM SMD

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Product Change Notice EN +2

242R7C

Active

Murata Power Solutions Inc.

FIXED IND 2.7UH 2.6A 39 MOHM SMD

Deep-Dive with AI

DocumentsDatasheet Product Change Notice EN +2

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	242R7C

Current Rating (Amps)	2.6 A
DC Resistance (DCR)	39 mOhm
Height - Seated (Max)	4.5 mm
Height - Seated (Max) [Max]	0.177 "
Inductance	2.7 µH
Mounting Type	Surface Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Nonstandard
Shielding	Unshielded
Size / Dimension [x]	5.8 mm
Size / Dimension [x]	0.228 in
Size / Dimension [y]	5.2 mm
Size / Dimension [y]	0.205 "
Type	Wirewound

24 Series

Part	Height - Seated (Max) [Max]	Height - Seated (Max)	DC Resistance (DCR)	Package / Case	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Current Rating (Amps)	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Shielding	Frequency - Self Resonant	Type	Inductance	DC Resistance (DCR) [Max]
Murata Power Solutions Inc. 243R3C	0.177 "	4.5 mm	42 mOhm	Nonstandard	Surface Mount	85 °C	-40 °C	2.4 A	5.8 mm	0.228 in	5.2 mm	0.205 "	Unshielded	53 MHz	Wirewound	3.3 µH
Murata Power Solutions Inc. 242R7C	0.177 "	4.5 mm	39 mOhm	Nonstandard	Surface Mount	85 °C	-40 °C	2.6 A	5.8 mm	0.228 in	5.2 mm	0.205 "	Unshielded		Wirewound	2.7 µH
Murata Power Solutions Inc. 24150C	0.177 "	4.5 mm	120 mOhm	Nonstandard	Surface Mount	85 °C	-40 °C	1.3 A	5.8 mm	0.228 in	5.2 mm	0.205 "	Unshielded	22 MHz	Wirewound	15 µH
Murata Power Solutions Inc. 24151C	0.177 "	4.5 mm		Nonstandard	Surface Mount	85 °C	-40 °C	400 mA	5.8 mm	0.228 in	5.2 mm	0.205 "	Unshielded	5.13 MHz	Wirewound	150 µH	1.1 Ohm
Murata Power Solutions Inc. 24330C	0.177 "	4.5 mm		Nonstandard	Surface Mount	85 °C	-40 °C	880 mA	5.8 mm	0.228 in	5.2 mm	0.205 "	Unshielded	13.1 MHz	Wirewound	33 µH	230 mOhm
Murata Power Solutions Inc. 24180C	0.177 "	4.5 mm		Nonstandard	Surface Mount	85 °C	-40 °C	1.26 A	5.8 mm	0.228 in	5.2 mm	0.205 "	Unshielded	20 MHz	Wirewound	18 µH	150 mOhm
Murata Power Solutions Inc. 24220C	0.177 "	4.5 mm	180 mOhm	Nonstandard	Surface Mount	85 °C	-40 °C	1.11 A	5.8 mm	0.228 in	5.2 mm	0.205 "	Unshielded	16.5 MHz	Wirewound	22 µH
Murata Power Solutions Inc. 24680C	0.177 "	4.5 mm		Nonstandard	Surface Mount	85 °C	-40 °C	610 mA	5.8 mm	0.228 in	5.2 mm	0.205 "	Unshielded	9.38 MHz	Wirewound	68 µH	460 mOhm
Murata Power Solutions Inc. 24221C	0.177 "	4.5 mm		Nonstandard	Surface Mount	85 °C	-40 °C	350 mA	5.8 mm	0.228 in	5.2 mm	0.205 "	Unshielded	4.24 MHz	Wirewound	220 µH	1.57 Ohm
Murata Power Solutions Inc. 244R7C	0.177 "	4.5 mm	50 mOhm	Nonstandard	Surface Mount	85 °C	-40 °C	2.1 A	5.8 mm	0.228 in	5.2 mm	0.205 "	Unshielded	45 MHz	Wirewound	4.7 ÁH

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	1500	$ 0.58
Newark	Each (Supplied on Cut Tape)	500	$ 0.69

Description

General part information

24 Series

2.7 µH Unshielded Wirewound Inductor 2.6 A 39mOhm Max Nonstandard
