LB11970FV-TLM-H

Active

Sanyo

SINGLE-PHASE FULL-WAVE DRIVER FO

Search across all available documentation for this part.

Active

Sanyo

SINGLE-PHASE FULL-WAVE DRIVER FO

Technical Specifications

Parameters and characteristics for this part

Specification	LB11970FV-TLM-H

Applications	Fan Motor Driver
Current - Output	1.2 A
Function	Driver - Fully Integrated, Control and Power Stage
Interface	PWM, Parallel
Motor Type - AC, DC	Brushless DC (BLDC)
Mounting Type	Surface Mount
Operating Temperature [Max]	90 °C
Operating Temperature [Min]	-30 °C
Output Configuration	Half Bridge (2)
Package / Case	18-LSOP
Package / Case [custom]	0.173 "
Package / Case [custom]	4.4 mm
Supplier Device Package	18-SSOP
Technology	Bipolar
Voltage - Load [Max]	16 V
Voltage - Load [Min]	3.5 V
Voltage - Supply [Max]	16 V
Voltage - Supply [Min]	4.5 V

Part	Applications	Voltage - Supply [Min]	Voltage - Supply [Max]	Motor Type - AC, DC	Interface	Function	Technology	Current - Output	Voltage - Load [Max]	Voltage - Load [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Output Configuration	Supplier Device Package	Package / Case [custom]	Package / Case [custom]	Package / Case	Mounting Type
Sanyo LB11970FV-TLM-H	Fan Motor Driver	4.5 V	16 V	Brushless DC (BLDC)	Parallel PWM	Driver - Fully Integrated Control and Power Stage	Bipolar	1.2 A	16 V	3.5 V	90 °C	-30 °C	Half Bridge (2)	18-SSOP	0.173 "	4.4 mm	18-LSOP	Surface Mount
Sanyo LB11970RV-TLM-H	Fan Motor Driver	4.5 V	16 V	Brushless DC (BLDC)	Parallel PWM	Driver - Fully Integrated Control and Power Stage	Bipolar	1.2 A	16 V	3.5 V	90 °C	-30 ░C	Half Bridge (2)	18-SSOP	0.173 "	4.4 mm	18-LSOP	Surface Mount

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	531	$ 0.57

General part information

Motor Driver Bipolar Parallel, PWM 18-SSOP

Technical documentation and resources

No documents available
