2982100
ActivePhoenix Contact
SSR RELAY SPST-NO 5A 3-33V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
2982100
ActivePhoenix Contact
SSR RELAY SPST-NO 5A 3-33V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 2982100 |
|---|---|
| Approval Agency | cURus, GL |
| Load Current | 5 A |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -25 °C |
| Output Type | DC |
| Package / Case | Module |
| Termination Style | PC Pin |
| Voltage - Input | 24 V |
| Voltage - Load [Max] | 33 V |
| Voltage - Load [Min] | 3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 37.49 | |
| 10 | $ 35.04 | |||
| 50 | $ 32.23 | |||
| 100 | $ 29.78 | |||
| 250 | $ 28.38 | |||
Description
General part information
298210 Series
Solid State SPST-NO (1 Form A) Module
Documents
Technical documentation and resources
