AA10S1200A

Obsolete

Delta Electronics

AC/DC POWER SUPPLY SINGLE-OUT 12V 0.833A 10W 4-PIN

Search across all available documentation for this part.

Obsolete

Delta Electronics

AC/DC POWER SUPPLY SINGLE-OUT 12V 0.833A 10W 4-PIN

Technical Specifications

Parameters and characteristics for this part

Part	Number of Outputs	Weight	Weight	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Approval Agency	Current - Output (Max) [Max]	Package / Case	Power (Watts)	Type	Efficiency	Features	Standard Number	Voltage - Output 1	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Load Regulation	Applications	Line Regulation
Delta Electronics AA10S0300A	1	0.119 lb	53.98 g	-25 °C	70 °C	Through Hole	CE UL	2.5 A	4-DIP Module	10 W	Enclosed	70 %	Universal Input	60950-1	3.3 V	2.06 in	23.5 mm	52.3 mm	0.93 in	27.2 mm	1.07 in	0.5 %	ITE (Commercial)	0.5 %
Delta Electronics AA10S2400A	1	0.119 lb	53.98 g	-25 °C	70 °C	Through Hole	CE UL		4-DIP Module	10 W	Enclosed	72 %	Universal Input	60950-1	24 V	2.06 in	23.5 mm	52.3 mm	0.93 in	27.2 mm	1.07 in	0.5 %	ITE (Commercial)	0.5 %
Delta Electronics AA10S1200A	1	0.119 lb	53.98 g	-25 °C	70 °C	Through Hole	CE UL	833 mA	4-DIP Module	10 W	Enclosed	76 %	Universal Input	60950-1	12 V	2.06 in	23.5 mm	52.3 mm	0.93 in	27.2 mm	1.07 in	0.5 %	ITE (Commercial)	0.5 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Enclosed AC DC Converters 1 Output 12V 833mA 85 ~ 264 VAC Input
