UOA-120-ALA
ObsoleteMueller Electric Co
VOLTAGE MONITORING RELAY
Deep-Dive with AI
Search across all available documentation for this part.
UOA-120-ALA
ObsoleteMueller Electric Co
VOLTAGE MONITORING RELAY
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | UOA-120-ALA |
|---|---|
| Circuit | DPDT (2 Form C) |
| Contact Rating @ Voltage | 5 A, 240 VAC |
| Delay Time [Max] | 0.5 s |
| Delay Time [Min] | 0.05 Sec |
| Mounting Type | Socketable |
| Trip Range [Max] | 135 V AC |
| Trip Range [Min] | 97 V AC |
| Trip Status | Energized High/Low |
| Type | Voltage Sensing AC |
| Voltage - Supply | 120 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 179.69 | |
Description
General part information
UOA-120 Series
Voltage Sensing AC 120VAC
Documents
Technical documentation and resources
No documents available
