PEH200XO4220MU2

Active

KEMET

CAP ALUM 2200UF 20% 385V SCREW

Search across all available documentation for this part.

Active

KEMET

CAP ALUM 2200UF 20% 385V SCREW

Technical Specifications

Parameters and characteristics for this part

Specification	PEH200XO4220MU2

Applications	General Purpose
Capacitance	2200 µF
ESR (Equivalent Series Resistance)	38 mOhm
Height - Seated (Max) [Max]	106 mm
Height - Seated (Max) [Max]	4.173 in
Lead Spacing	32 mm
Lead Spacing	1.26 in
Lifetime @ Temp.	15000 Hrs
Mounting Type	Chassis Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Radial, Can - Screw Terminals
Polarization	Polar
Ripple Current @ High Frequency	26.1 A
Ripple Current @ Low Frequency	9.6 A
Size / Dimension [diameter]	66.6 mm
Size / Dimension [diameter]	2.622 in
Tolerance	20 %
Voltage - Rated	385 V

Part	Size / Dimension [diameter]	Size / Dimension [diameter]	ESR (Equivalent Series Resistance)	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Lifetime @ Temp.	Lead Spacing	Lead Spacing	Polarization	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Ripple Current @ High Frequency	Mounting Type	Voltage - Rated	Capacitance	Tolerance	Applications	Ripple Current @ Low Frequency
KEMET PEH200XO4220MU2	66.6 mm	2.622 in	38 mOhm	106 mm	4.173 in	15000 Hrs	32 mm	1.26 in	Polar	85 °C	-40 °C	Radial Can - Screw Terminals	26.1 A	Chassis Mount	385 V	2200 µF	20 %	General Purpose	9.6 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 56.49

General part information

2200 µF 385 V Aluminum Electrolytic Capacitors Radial, Can - Screw Terminals 38mOhm @ 100Hz 15000 Hrs @ 85°C
