Q8F1BXXR12E
ActiveAPEM
INDICATOR 12V 8MM FLUSH RED
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
Q8F1BXXR12E
ActiveAPEM
INDICATOR 12V 8MM FLUSH RED
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | Q8F1BXXR12E |
|---|---|
| Ingress Protection | IP67 |
| Lamp Color | Red |
| Lens Color | Red |
| Lens Size | T-1 3/4 |
| Lens Size | 5 mm |
| Lens Transparency | Diffused |
| Millicandela Rating | 12 mcd |
| Panel Cutout Dimensions [custom] | 0.31 in |
| Panel Cutout Dimensions [custom] | 7.87 mm |
| Panel Cutout Shape | Round |
| Ratings | DC |
| Termination Style | Solder Lug |
| Type | LED |
| Viewing Angle | 100 ° |
| Voltage | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 15.51 | |
| 25 | $ 11.24 | |||
| 100 | $ 10.20 | |||
| 500 | $ 9.35 | |||
| 1000 | $ 9.08 | |||
Description
General part information
Q8F1BXXR Series
LED Panel Indicator Red Diffused 100° 12V 20mA Solder Lug
Documents
Technical documentation and resources
