AM10OW-2405SNZ-LM

Active

aimtec

DC DC CONVERTER 5V 10W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AM10OW-2405SNZ-LM

Active

aimtec

DC DC CONVERTER 5V 10W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	AM10OW-2405SNZ-LM

Applications	ITE (Commercial)
Current - Output (Max) [Max]	2 A
Efficiency	84 %
Features	Remote On/Off
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Power (Watts)	10 W
Size / Dimension [x]	1.63 "
Size / Dimension [x]	41.4 mm
Size / Dimension [y]	0.87 in
Size / Dimension [y]	22 mm
Size / Dimension [z]	7 mm
Size / Dimension [z]	0.28 "
Type	Isolated Module
Voltage - Input (Max) [Max]	36 V
Voltage - Input (Min) [Min]	9 V
Voltage - Isolation	1.5 kV
Voltage - Output 1	5 V

AM10O Series

Part	Voltage - Input (Min) [Min]	Number of Outputs	Type	Efficiency	Power (Watts)	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Features	Current - Output (Max) [Max]	Voltage - Isolation	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Output 1	Voltage - Input (Max) [Max]	Mounting Type	Applications	Size / Dimension [z]	Size / Dimension [y]	Package / Case
aimtec AM10OW-2405SNZ	9 V	1	Isolated Module	84 %	10 W	1.54 in	6.1 mm	0.82 "	0.24 "	39.2 mm	20.8 mm	Remote On/Off	2 A	1.5 kV	85 °C	-40 °C	5 V	36 V	Through Hole	ITE (Commercial)
aimtec AM10OW-2415SNZ	9 V	1	Isolated Module	88 %	10 W	1.54 in	6.1 mm	0.82 "	0.24 "	39.2 mm	20.8 mm	Remote On/Off	667 mA	1.5 kV	85 °C	-40 °C	15 V	36 V	Through Hole	ITE (Commercial)
aimtec AM10OW-2412SNZ-LM	9 V	1	Isolated Module	97 %	10 W	1.54 in	6.1 mm	0.82 "	0.24 "	39.2 mm	20.8 mm	Remote On/Off	833 mA	1.5 kV	85 °C	-40 °C	12 V	36 V	Through Hole	ITE (Commercial)
aimtec AM10OW-2412SNZ-M	9 V	1	Isolated Module	97 %	10 W	1.54 in	6.1 mm	0.82 "	0.24 "	39.2 mm	20.8 mm	Remote On/Off	833 mA	1.5 kV	85 °C	-40 °C	12 V	36 V	Through Hole	ITE (Commercial)
aimtec AM10OW-2405SNZ-LM	9 V	1	Isolated Module	84 %	10 W	1.63 "		0.87 in	0.28 "	41.4 mm		Remote On/Off	2 A	1.5 kV	85 °C	-40 °C	5 V	36 V	Through Hole	ITE (Commercial)	7 mm	22 mm
aimtec AM10OW-2412SNZ-L	9 V	1	Isolated Module	97 %	10 W	1.54 in	6.1 mm	0.82 "	0.24 "	39.2 mm	20.8 mm	Remote On/Off	833 mA	1.5 kV	85 °C	-40 °C	12 V	36 V	Through Hole	ITE (Commercial)
aimtec AM10OW-2415SNZ-LM	9 V	1	Isolated Module	88 %	10 W	1.54 in	6.1 mm	0.82 "	0.24 "	39.2 mm	20.8 mm	Remote On/Off	667 mA	1.5 kV	85 °C	-40 °C	15 V	36 V	Through Hole	ITE (Commercial)
aimtec AM10OW-2415SNZ-M	9 V	1	Isolated Module	88 %	10 W	1.54 in	6.1 mm	0.82 "	0.24 "	39.2 mm	20.8 mm	Remote On/Off	667 mA	1.5 kV	85 °C	-40 °C	15 V	36 V	Through Hole	ITE (Commercial)			6-DIP Module
aimtec AM10OW-2405SNZ-M	9 V	1	Isolated Module	84 %	10 W	1.54 in	6.1 mm	0.82 "	0.24 "	39.2 mm	20.8 mm	Remote On/Off	2 A	1.5 kV	85 °C	-40 °C	5 V	36 V	Through Hole	ITE (Commercial)
aimtec AM10OW-2405SNZ-L	9 V	1	Isolated Module	84 %	10 W	1.54 in	6.1 mm	0.82 "	0.24 "	39.2 mm	20.8 mm	Remote On/Off	2 A	1.5 kV	85 °C	-40 °C	5 V	36 V	Through Hole	ITE (Commercial)

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 23.24
		50	$ 22.31
		100	$ 21.41
		200	$ 20.34
		400	$ 19.12
		800	$ 18.55
		1600	$ 17.45
		3200	$ 16.92

Description

General part information

AM10O Series

Isolated Module DC DC Converter 1 Output 5V 2A 9V - 36V Input
