TRI 10-2422

Active

Traco Power

DC DC CONVERTER +/-12V 10W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

TRI 10-2422

Active

Traco Power

DC DC CONVERTER +/-12V 10W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	TRI 10-2422

Applications	ITE (Commercial)
Approval Agency	CB, cURus
Current - Output (Max) [Max]	416 mA
Efficiency	88 %
Mounting Type	Through Hole
Number of Outputs	2
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	24-DIP Module, 6 Leads
Power (Watts)	10 W
Size / Dimension [x]	1.25 "
Size / Dimension [x]	31.8 mm
Size / Dimension [y]	20.3 mm
Size / Dimension [y]	0.8 in
Size / Dimension [z]	12 mm
Size / Dimension [z]	0.47 "
Type	Isolated Module
Voltage - Input (Max) [Max]	36 V
Voltage - Input (Min) [Min]	18 V
Voltage - Isolation	5000 V
Voltage - Output 1	12 V
Voltage - Output 2	-12 V

TRI 10 Series

Part	Current - Output (Max) [Max]	Number of Outputs	Power (Watts)	Applications	Voltage - Isolation	Voltage - Input (Min) [Min]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Voltage - Input (Max) [Max]	Efficiency	Package / Case	Voltage - Output 1	Type	Approval Agency	Voltage - Output 2	Current - Output (Max)	Current - Output (Max)
Traco Power TRI 10-4813	666 mA	1	10 W	ITE (Commercial)	5000 V	36 V	20.3 mm	12 mm	1.25 "	31.8 mm	0.47 "	0.8 in	85 °C	-40 °C	Through Hole	75 V	88 %	24-DIP Module 5 Leads	15 V	Isolated Module	CB cURus
Traco Power TRI 10-4810	2.7 A	1	8.9 W	ITE (Commercial)	5000 V	36 V	20.3 mm	12 mm	1.25 "	31.8 mm	0.47 "	0.8 in	85 °C	-40 °C	Through Hole	75 V	81 %	24-DIP Module 5 Leads	3.3 V	Isolated Module	CB cURus
Traco Power TRI 10-2422	416 mA	2	10 W	ITE (Commercial)	5000 V	18 V	20.3 mm	12 mm	1.25 "	31.8 mm	0.47 "	0.8 in	85 °C	-40 °C	Through Hole	36 V	88 %	24-DIP Module 6 Leads	12 V	Isolated Module	CB cURus	-12 V
Traco Power TRI 10-2423		2	10 W	ITE (Commercial)	5000 V	18 V	20.3 mm	12 mm	1.25 "	31.8 mm	0.47 "	0.8 in	85 °C	-40 °C	Through Hole	36 V	87 %	24-DIP Module 6 Leads	15 V	Isolated Module	CB cURus	-15 V	333 mA	333 mA
Traco Power TRI 10-2412	833 mA	1	10 W	ITE (Commercial)	5000 V	18 V	20.3 mm	12 mm	1.25 "	31.8 mm	0.47 "	0.8 in	85 °C	-40 °C	Through Hole	36 V	87 %	24-DIP Module 5 Leads	12 V	Isolated Module	CB cURus
Traco Power TRI 10-4811	2 A	1	10 W	ITE (Commercial)	5000 V	36 V	20.3 mm	12 mm	1.25 "	31.8 mm	0.47 "	0.8 in	85 °C	-40 °C	Through Hole	75 V	84 %	24-DIP Module 5 Leads	5.1 V	Isolated Module	CB cURus

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 63.60
		10	$ 59.02
		25	$ 57.76
		50	$ 56.82
		100	$ 55.89
		250	$ 46.34

Description

General part information

TRI 10 Series

Isolated Module DC DC Converter 2 Output 12V -12V 416mA, 416mA 18V - 36V Input
