Technical Specifications
Parameters and characteristics for this part
| Specification | 1800934 |
|---|---|
| Color | Black |
| Contact Mating Finish | Tin |
| Current - IEC | 12 A |
| Insulation Height | 0.591 in |
| Insulation Height | 15 mm |
| Mounting Type | Free Hanging (In-Line) |
| Number of Levels | 1 |
| Number of Positions | 2 |
| Pitch [x] | 0.2 in |
| Pitch [x] | 5.08 mm |
| Positions Per Level | 2 |
| Screw Size | M3 |
| Termination Style | Screw - Rising Cage Clamp |
| Torque - Screw [Max] | 0.6 Nm |
| Torque - Screw [Max] | 5.3 Lb-In |
| Torque - Screw [Min] | 4.4 Lb-In |
| Torque - Screw [Min] | 0.5 Nm |
| Type | Plug, Female Sockets |
| Voltage - IEC | 250 V |
| Wire Gauge or Range - AWG [Max] | 30 AWG |
| Wire Gauge or Range - AWG [Min] | 12 AWG |
| Wire Gauge or Range - mm² [Max] | 2.5 mm² |
| Wire Gauge or Range - mm² [Min] | 0.2 mm² |
| Wire Strip Length | 7 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
MSTBT Series
Pluggable Terminal Blocks 4 Pos 5mm pitch Plug 24-12 AWG Screw
