NVD0.4YJJ-M6G
ActiveEOS Power India Private Ltd
DC DC CONVERTER +/-15V 6W
Deep-Dive with AI
Search across all available documentation for this part.
NVD0.4YJJ-M6G
ActiveEOS Power India Private Ltd
DC DC CONVERTER +/-15V 6W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | NVD0.4YJJ-M6G |
|---|---|
| Applications | ITE (Commercial) |
| Efficiency | 84 % |
| Features | OCP |
| Mounting Type | Surface Mount |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 110 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 24-SMD Module, 14 Leads |
| Power (Watts) | 6 W |
| Size / Dimension [x] | 1.3 " |
| Size / Dimension [x] | 33 mm |
| Size / Dimension [y] | 0.81 in |
| Size / Dimension [y] | 20.6 mm |
| Size / Dimension [z] | 8.4 mm |
| Size / Dimension [z] | 0.33 in |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 36 V |
| Voltage - Input (Min) [Min] | 18 V |
| Voltage - Isolation | 1.5 kV |
| Voltage - Output 1 | 15 V |
| Voltage - Output 2 | -15 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 81.72 | |
| 5 | $ 77.04 | |||
| 10 | $ 75.11 | |||
| 25 | $ 72.63 | |||
| 50 | $ 70.81 | |||
| 100 | $ 69.03 | |||
Description
General part information
NVD0.4 Series
Isolated Module DC DC Converter 2 Output 15V -15V 200mA, 200mA 18V - 36V Input
