Technical Specifications
Parameters and characteristics for this part
| Specification | FKX006A0X3-SRZ |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) [Max] | 6 A |
| Efficiency | 93.5 % |
| Features | Remote On/Off, UVLO, OCP, OTP |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 7-SMD Module |
| Size / Dimension [x] | 9 mm |
| Size / Dimension [x] | 0.35 in |
| Size / Dimension [y] | 6.8 mm |
| Size / Dimension [y] | 0.27 in |
| Size / Dimension [z] | 7.2 mm |
| Size / Dimension [z] | 0.29 " |
| Supplier Device Package | Module |
| Type | Non-Isolated PoL Module |
| Voltage - Input (Max) [Max] | 14.4 V |
| Voltage - Input (Min) [Min] | 4.5 V |
| Voltage - Output 1 [Max] | 5.5 V |
| Voltage - Output 1 [Min] | 0.6 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
FKX006 Series
Non-Isolated DC/DC Converters 4.5-14.4Vin 0.6-5.5V 6A Neg SMT NonIso
