AA-024-12-22-00-00

Active

Laird Thermal Systems, Inc.

THERMOELECT ASSY AIR-AIR 25W

Search across all available documentation for this part.

Active

Laird Thermal Systems, Inc.

THERMOELECT ASSY AIR-AIR 25W

Technical Specifications

Parameters and characteristics for this part

Specification	AA-024-12-22-00-00

Current	2.4 A
Dimensions - Overall [x]	100 mm
Dimensions - Overall [y]	82.2 mm
Dimensions - Overall [z]	120.9 mm
Fan Location	Cold Side / Warm Side
Heat Transfer Type	Air to Air
Operating Temperature [Max] [custom]	51 °C
Operating Temperature [Min] [custom]	-10 °C
Power - Cooling	25 W
Power - Input	29 W
Voltage	12 V
Weight	589.7 g
Weight	1.3 lbs

Part	Weight	Weight	Operating Temperature [Min] [custom]	Operating Temperature [Max] [custom]	Power - Cooling	Fan Location	Heat Transfer Type	Current	Power - Input	Voltage	Dimensions - Overall [z]	Dimensions - Overall [y]	Dimensions - Overall [x]
Laird Thermal Systems, Inc. AA-024-12-22-00-00	589.7 g	1.3 lbs	-10 °C	51 °C	25 W	Cold Side / Warm Side	Air to Air	2.4 A	29 W	12 V	120.9 mm	82.2 mm	100 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Air to Air Thermoelectric Assembly 25 W

Technical documentation and resources
