LP-24-2000
ActiveSignal Transformer
POWER TRANSFORMER 1500VRMS 48VA 8 TERMINAL PIN THRU-HOLE
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | LP-24-2000 |
|---|---|
| Center Tap | False |
| Current - Output (Max) [custom] | 2 A |
| Current - Output (Max) [custom] | 4 A |
| Height - Seated (Max) [Max] [z] | 34.9 mm |
| Mounting Type | Through Hole |
| Power - Max [Max] | 48 VA |
| Primary Winding(s) | Dual |
| Secondary Winding(s) | Dual |
| Size / Dimension [x] | 79.2 mm |
| Size / Dimension [y] | 2.5 in |
| Termination Style | PC Pin |
| Type | Semi-Toroidal |
| Voltage - Isolation | 1500 VAC |
| Voltage - Primary | 115 V, 230 V |
| Voltage - Secondary (Full Load) | 24 V, 12 V |
| Weight | 1.4 lbs |
| Weight | 635 g |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
LP Series
Power Transformers 50\60 Hz, Laminated Transformer
