Q-3303A0001072I

Active

Amphenol Custom Cable

CBL ASSY SMA PLUG TO PLUG 6'

Deep-Dive with AI

Search across all available documentation for this part.

Q-3303A0001072I

Active

Amphenol Custom Cable

CBL ASSY SMA PLUG TO PLUG 6'

Deep-Dive with AI

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	Q-3303A0001072I

1st Connector	SMA Plug, Right Angle
1st Connector Mounting Type	Free Hanging (In-Line)
1st Contact Gender	Male
2nd Connector	SMA Plug
2nd Connector Mounting Type	Free Hanging (In-Line)
2nd Contact Gender	Male
Cable Impedance	50 Ohms
Cable Type	RG-178
Color	Copper
Connector Impedance	50 Ohms
Features	Shielded
Frequency - Max [Max]	3 GHz
Length	6 ft
Length	72 in
Length	1.8 m
Overall Impedance	50 Ohms
Style	SMA to SMA

Q-3303A0 Series

Part	1st Contact Gender	Cable Impedance	Style	Length	Length	Frequency - Max [Max]	2nd Connector Mounting Type	1st Connector Mounting Type	1st Connector	Features	Cable Type	Connector Impedance	Color	2nd Contact Gender	Overall Impedance	2nd Connector	Length	Length [x]	Length [x]
Amphenol Custom Cable Q-3303A0001009I	Male	50 Ohms	SMA to SMA	9 "	228.6 mm	3 GHz	Free Hanging (In-Line)	Free Hanging (In-Line)	Right Angle SMA Plug	Shielded	RG-178	50 Ohms	Copper	Male	50 Ohms	SMA Plug
Amphenol Custom Cable Q-3303A0001003M	Male	50 Ohms	SMA to SMA	118.1 in	3 m	3 GHz	Free Hanging (In-Line)	Free Hanging (In-Line)	Right Angle SMA Plug	Shielded	RG-178	50 Ohms	Copper	Male	50 Ohms	SMA Plug	9.8 '
Amphenol Custom Cable Q-3303A0001.75M	Male	50 Ohms	SMA to SMA	29.53 "	750 mm	3 GHz	Free Hanging (In-Line)	Free Hanging (In-Line)	Right Angle SMA Plug	Shielded	RG-178	50 Ohms	Copper	Male	50 Ohms	SMA Plug
Amphenol Custom Cable Q-3303A0001001M	Male	50 Ohms	SMA to SMA	39.4 in	1 m	3 GHz	Free Hanging (In-Line)	Free Hanging (In-Line)	Right Angle SMA Plug	Shielded	RG-178	50 Ohms	Copper	Male	50 Ohms	SMA Plug	3.3 ft
Amphenol Custom Cable Q-3303A0001108I	Male	50 Ohms	SMA to SMA	108 in	2.7 m	3 GHz	Free Hanging (In-Line)	Free Hanging (In-Line)	Right Angle SMA Plug	Shielded	RG-178	50 Ohms	Copper	Male	50 Ohms	SMA Plug	9 ft
Amphenol Custom Cable Q-3303A0001072I	Male	50 Ohms	SMA to SMA	72 in	1.8 m	3 GHz	Free Hanging (In-Line)	Free Hanging (In-Line)	Right Angle SMA Plug	Shielded	RG-178	50 Ohms	Copper	Male	50 Ohms	SMA Plug	6 ft
Amphenol Custom Cable Q-3303A0001002M	Male	50 Ohms	SMA to SMA	78.7 in	2 m	3 GHz	Free Hanging (In-Line)	Free Hanging (In-Line)	Right Angle SMA Plug	Shielded	RG-178	50 Ohms	Copper	Male	50 Ohms	SMA Plug	6.6 ft
Amphenol Custom Cable Q-3303A0001003I	Male	50 Ohms	SMA to SMA	3 in	76.2 mm	3 GHz	Free Hanging (In-Line)	Free Hanging (In-Line)	Right Angle SMA Plug	Shielded	RG-178	50 Ohms	Copper	Male	50 Ohms	SMA Plug
Amphenol Custom Cable Q-3303A00012.5M	Male	50 Ohms	SMA to SMA	98.4 in	2.5 m	3 GHz	Free Hanging (In-Line)	Free Hanging (In-Line)	Right Angle SMA Plug	Shielded	RG-178	50 Ohms	Copper	Male	50 Ohms	SMA Plug	8.2 '
Amphenol Custom Cable Q-3303A0001.25M	Male	50 Ohms	SMA to SMA			3 GHz	Free Hanging (In-Line)	Free Hanging (In-Line)	Right Angle SMA Plug	Shielded	RG-178	50 Ohms	Copper	Male	50 Ohms	SMA Plug		9.843 "	250 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bag	1	$ 105.22
		25	$ 103.15
		50	$ 101.08
		100	$ 99.02
		250	$ 96.95

Description

General part information

Q-3303A0 Series

Cable Assembly Coaxial SMA to SMA RG-178 72.0" (1.8m) 6.0'

Documents

Technical documentation and resources

No documents available
