M10578-A3-U1

Active

Antenova

M10578-A3 GPS RECEIVER EVALUATION KIT

Search across all available documentation for this part.

Active

Antenova

M10578-A3 GPS RECEIVER EVALUATION KIT

Technical Specifications

Parameters and characteristics for this part

Specification	M10578-A3-U1

For Use With/Related Products	M10578-A3
Frequency	1575.42 MHz
Supplied Contents	Board(s)
Type	GNSS (GPS)

Part	Supplier Device Package	Frequency	Sensitivity	Mounting Type	Voltage - Supply	Data Interface	Package / Case	Applications	Current - Receiving	Operating Temperature [Max]	Operating Temperature [Min]	Modulation or Protocol	For Use With/Related Products	Supplied Contents	Type
Antenova M10578-A2	Module	1.575 GHz	-165 dBm	Surface Mount	3.3 V	UART	Module	General Purpose	24 mA	85 °C	-40 °C	GPS
Antenova M10578-A3-U1		1575.42 MHz											M10578-A3	Board(s)	GNSS (GPS)
Antenova M10578-A3	Module	1.575 GHz	-165 dBm	Surface Mount	3.3 V	UART	Module	General Purpose	28 mA	85 °C	-40 °C	BeiDou Galileo GLONASS GNSS GPS

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 124.76

General part information

RADIONOVA® M10578-A3 GNSS (GPS) 1575.42MHz Evaluation Board
