1800F B591000

Active

Belden Inc.

#24 PR FHDPE BRD PVC

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Broadcast and Professional AV Solutions

1800F B591000

Active

Belden Inc.

#24 PR FHDPE BRD PVC

Deep-Dive with AI

DocumentsDatasheet Broadcast and Professional AV Solutions

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	1800F B591000

Cable Type	Microphone
Conductor Insulation	Foam Polyethylene (FPE)
Conductor Material	Copper, Bare
Conductor Strand	40 AWG, 42
Features	Drain Wire
Jacket (Insulation) Diameter [diameter]	0.211 in
Jacket (Insulation) Diameter [diameter]	5.36 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC), Riser
Jacket (Insulation) Thickness	0.94 mm
Jacket (Insulation) Thickness	0.037 in
Jacket Color	Black
Length	1000 ft
Length	304.8 m
Number of Conductors	2
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-20 C
Ratings	UL Style, Riser
Shield Coverage	95 %
Shield Material	Copper, Tinned
Shield Type	Braid
Usage	Audio
Voltage	100 V
Wire Gauge	24 AWG

1800F Series

Part	Voltage	Ratings	Conductor Insulation	Number of Conductors	Jacket (Insulation) Material	Wire Gauge	Operating Temperature [Min]	Operating Temperature [Max]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Material	Jacket Color	Conductor Strand	Length	Length	Usage	Shield Material	Features	Shield Type	Cable Type	Shield Coverage	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Length [x]	Length [x]
Belden Inc. 1800F B59U1000	100 V	Riser UL Style	Foam Polyethylene (FPE)	2	Poly-Vinyl Chloride (PVC) Riser	24 AWG	-20 C	60 °C	0.211 in	5.36 mm	Copper Bare	Black	40 AWG 42	1000 ft	304.8 m	Audio	Copper Tinned	Drain Wire	Braid	Microphone	95 %	0.94 mm	0.037 in
Belden Inc. 1800F B591000	100 V	Riser UL Style	Foam Polyethylene (FPE)	2	Poly-Vinyl Chloride (PVC) Riser	24 AWG	-20 C	60 °C	0.211 in	5.36 mm	Copper Bare	Black	40 AWG 42	1000 ft	304.8 m	Audio	Copper Tinned	Drain Wire	Braid	Microphone	95 %	0.94 mm	0.037 in
Belden Inc. 1800F B59500	100 V	Riser UL Style	Foam Polyethylene (FPE)	2	Poly-Vinyl Chloride (PVC) Riser	24 AWG	-20 C	60 °C	0.211 in	5.36 mm	Copper Bare	Black	40 AWG 42			Audio	Copper Tinned	Drain Wire	Braid	Microphone	95 %	0.94 mm	0.037 in	500 '	152.4 m
Belden Inc. 1800F G7XU1000	100 V	Riser UL Style	Foam Polyethylene (FPE)	2	Poly-Vinyl Chloride (PVC) Riser	24 AWG	-20 C	60 °C	0.211 in	5.36 mm	Copper Bare	Blue	40 AWG 42	1000 ft	304.8 m	Audio	Copper Tinned	Drain Wire	Braid	Microphone	95 %	0.94 mm	0.037 in
Belden Inc. 1800F Z4BU1000	100 V	Riser UL Style	Foam Polyethylene (FPE)	2	Poly-Vinyl Chloride (PVC) Riser	24 AWG	-20 C	60 °C	0.211 in	5.36 mm	Copper Bare	Violet	40 AWG 42	1000 ft	304.8 m	Audio	Copper Tinned	Drain Wire	Braid	Microphone	95 %	0.94 mm	0.037 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 2.33

Description

General part information

1800F Series

2 (1 Pair) Conductor Microphone Cable Black 24 AWG Braid 1000.0' (304.8m)

Documents

Technical documentation and resources

Datasheet

Broadcast and Professional AV Solutions

Datasheet
