SRU6013-4R2Y

Active

Bourns Inc.

IND6.2X6.5X1.45MM,4.2UH30%2.1A,SHDSMD /TAPE & REEL - 7" REEL

Search across all available documentation for this part.

Active

Bourns Inc.

IND6.2X6.5X1.45MM,4.2UH30%2.1A,SHDSMD /TAPE & REEL - 7" REEL

Technical Specifications

Parameters and characteristics for this part

Part	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Inductance Frequency - Test	Type	Q @ Freq	Tolerance	DC Resistance (DCR) [Max]	Frequency - Self Resonant	Operating Temperature [Max]	Operating Temperature [Min]	Height - Seated (Max) [Max]	Height - Seated (Max)	Material - Core	Current Rating (Amps)	Mounting Type	Package / Case	Shielding	Inductance	Current - Saturation (Isat)
Bourns Inc. SRU6013-4R2Y	0.256 "	6.5 mm	6.2 mm	0.244 in	100 kHz	Drum Core Wirewound	7.96 MHz 10	30 %	75 mOhm	55 MHz	125 °C	-40 °C	0.063 in	1.6 mm	Ferrite	2.1 A	Surface Mount	Nonstandard	Shielded	4.2 µH
Bourns Inc. SRU6013-680Y	0.256 "	6.5 mm	6.2 mm	0.244 in	100 kHz	Drum Core Wirewound	2.52 MHz 10	30 %		10 MHz	125 °C	-40 °C	0.063 in	1.6 mm	Ferrite	600 mA	Surface Mount	Nonstandard	Shielded	68 µH	400 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

4.2 µH Shielded Drum Core, Wirewound Inductor 2.1 A 75mOhm Max Nonstandard
