A16894-25
ObsoleteLaird Technologies - Thermal Materials
THERM PAD 457.2X457.2MM GRAY
Deep-Dive with AI
Search across all available documentation for this part.
A16894-25
ObsoleteLaird Technologies - Thermal Materials
THERM PAD 457.2X457.2MM GRAY
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | A16894-25 |
|---|---|
| Adhesive | Tacky - One Side |
| Color | Gray |
| Outline [x] | 457.2 mm |
| Outline [y] | 457.2 mm |
| Shape | Square |
| Thermal Conductivity | 1.6 W/m-K |
| Thickness | 0.25 in |
| Thickness | 6.35 mm |
| Type | Gap Filler Pad, Sheet |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
A16894 Series
Thermal Pad Gray 457.20mm x 457.20mm Square Tacky - One Side
