1PS70SB85,115
ActiveFreescale Semiconductor - NXP
DIODE ARR SCHOTT 15V 30MA SOT323
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
1PS70SB85,115
ActiveFreescale Semiconductor - NXP
DIODE ARR SCHOTT 15V 30MA SOT323
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 1PS70SB85,115 |
|---|---|
| Current - Average Rectified (Io) (per Diode) | 30 mA |
| Diode Configuration | 1 Pair Common Cathode |
| Grade | Automotive |
| Mounting Type | Surface Mount |
| Operating Temperature - Junction | 125 °C |
| Package / Case | SC-70, SOT-323 |
| Qualification | AEC-Q100 |
| Speed | Any Speed |
| Speed | 200 mA |
| Supplier Device Package | SOT-323 |
| Technology | Schottky |
| Voltage - Forward (Vf) (Max) @ If | 700 mV |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 3116 | $ 0.10 | |
| Cut Tape (CT) | 1 | $ 0.42 | ||
| 10 | $ 0.33 | |||
| 100 | $ 0.20 | |||
| 500 | $ 0.18 | |||
| 1000 | $ 0.12 | |||
| Digi-Reel® | 1 | $ 0.42 | ||
| 10 | $ 0.33 | |||
| 100 | $ 0.20 | |||
| 500 | $ 0.18 | |||
| 1000 | $ 0.12 | |||
| Tape & Reel (TR) | 3000 | $ 0.11 | ||
| 6000 | $ 0.11 | |||
| 9000 | $ 0.10 | |||
| 30000 | $ 0.10 | |||
| 75000 | $ 0.09 | |||
Description
General part information
1PS70SB85 Series
Diode Array 1 Pair Common Cathode 15 V 30mA (DC) Surface Mount SC-70, SOT-323
