APC-03208P
ActiveEuropean Thermodynamics Ltd
TE CYCLING, 20X20X3.7MM
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | APC-03208P |
|---|---|
| Current - Max [Max] | 7.4 A |
| Delta Tmax @ Th | 64 °C |
| Features | Lead Wires |
| Height [z] | 3.7 mm |
| Number of Stages | 1 |
| Operating Temperature | 194 °F |
| Qmax @ Th | 16.9 W |
| Size / Dimension [x] | 24.4 mm |
| Size / Dimension [y] | 20 mm |
| Voltage - Max [Max] | 3.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 18.20 | |
| 5 | $ 17.11 | |||
| 10 | $ 16.66 | |||
| 25 | $ 16.08 | |||
| 50 | $ 15.66 | |||
| 100 | $ 15.24 | |||
Description
General part information
APC-03208 Series
Peltier Module 16.9W @ 27°C 7.4 A 90°C
