LE T Q8WP-MBNB-34-0-A40-R18-Z

Active

ams-OSRAM USA INC.

LED OSRAM OSTAR GREEN 530NM SMD

Search across all available documentation for this part.

Active

ams-OSRAM USA INC.

LED OSRAM OSTAR GREEN 530NM SMD

Technical Specifications

Parameters and characteristics for this part

Specification	LE T Q8WP-MBNB-34-0-A40-R18-Z

Color	Green
Current - Max [Max]	5 A
Height - Seated (Max)	1.35 mm
Height - Seated (Max) [Max] [z]	0.053 in
Lumens/Watt @ Current - Test	67 lm/W
Luminous Flux @ Current/Temperature	337 lm
Luminous Flux @ Current/Temperature [Max]	450 lm
Luminous Flux @ Current/Temperature [Min]	224 lm
Mounting Type	Surface Mount
Package / Case	2-SMD, No Lead Exposed Pad
Size / Dimension [x]	3.9 mm
Size / Dimension [x]	0.154 in
Size / Dimension [y]	0.144 in
Size / Dimension [y]	3.65 mm
Supplier Device Package	SMD
Viewing Angle	120 °
Voltage - Forward (Vf) (Typ)	3.6 V
Wavelength	530 nm

Part	Current - Max [Max]	Lumens/Watt @ Current - Test	Supplier Device Package	Color	Height - Seated (Max)	Height - Seated (Max) [Max] [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Mounting Type	Viewing Angle	Package / Case	Voltage - Forward (Vf) (Typ)	Luminous Flux @ Current/Temperature [Max]	Luminous Flux @ Current/Temperature	Luminous Flux @ Current/Temperature [Min]	Wavelength	Current - Test
ams-OSRAM USA INC. LE T Q8WP-MBNB-34-0-A40-R18-Z	5 A	67 lm/W	SMD	Green	1.35 mm	0.053 in	0.144 in	3.65 mm	3.9 mm	0.154 in	Surface Mount	120 °	2-SMD No Lead Exposed Pad	3.6 V	450 lm	337 lm	224 lm	530 nm
ams-OSRAM USA INC. LE T Q8WM-KXKZ-24	500 mA	74 lm/W	2-SMD	Green			0.144 in	3.65 mm	3.9 mm	0.154 in	Surface Mount	120 °	2-SMD No Lead Exposed Pad	3.55 V	112 lm	92 lm	71 lm	530 nm	350 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

LED Lighting Color OSRAM OSTAR Green 530nm (Typ) 2-SMD, No Lead Exposed Pad
