ISO-24-AFN
ActiveATC-Diversified Electronics
SINGLE CHANNEL ISOLATED SWITCH
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
ISO-24-AFN
ActiveATC-Diversified Electronics
SINGLE CHANNEL ISOLATED SWITCH
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | ISO-24-AFN |
|---|---|
| Approval Agency | UL |
| Coil Type | Non Latching |
| Coil Voltage | 24 VAC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 5 A |
| Mounting Type | Chassis Mount |
| Operate Time | 6 ms |
| Operating Temperature [Max] | 55 °C |
| Operating Temperature [Min] | -20 C |
| Relay Type | General Purpose |
| Release Time | 2.5 ms |
| Switching Voltage | 120 VAC |
| Termination Style | Screw Terminal |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 179.19 | |
Description
General part information
ISO-24 Series
General Purpose Relay SPST-NO (1 Form A) 24VAC Coil Chassis Mount
