34.81.7.012.8240

Active

Finder Relays, Inc.

SOLID STATE PCB/PLUG-IN RELAY, S

Search across all available documentation for this part.

Active

Finder Relays, Inc.

SOLID STATE PCB/PLUG-IN RELAY, S

Technical Specifications

Parameters and characteristics for this part

Part	Supplier Device Package	Termination Style	Voltage - Load [Min]	Voltage - Load [Max]	Voltage - Input	Output Type	Package / Case	Load Current	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Approval Agency
Finder Relays, Inc. 34.81.7.012.9024	4-SIP	PC Pin	1.5 V	33 V	12 VDC	DC	4-SIP	6 A	Through Hole	-20 C	70 °C	CE cURus EAC UKCA
Finder Relays, Inc. 34.81.7.005.9024	4-SIP	PC Pin	1.5 V	33 V	5 VDC	DC	4-SIP	6 A	Through Hole	-20 C	70 °C	CE cURus EAC UKCA
Finder Relays, Inc. 34.81.7.060.8240	4-SIP	PC Pin	12 V	275 V	60 VDC	AC Zero Cross	4-SIP	2 A	Through Hole	-20 C	50 °C	CE cURus EAC UKCA
Finder Relays, Inc. 34.81.7.012.8240	4-SIP	PC Pin	12 V	275 V	12 VDC	AC Zero Cross	4-SIP	2 A	Through Hole	-20 C	50 °C	CE cURus EAC UKCA
Finder Relays, Inc. 34.81.7.005.8240	4-SIP	PC Pin	12 V	275 V	5 VDC	AC Zero Cross	4-SIP	2 A	Through Hole	-20 C	50 °C	CE cURus EAC UKCA
Finder Relays, Inc. 34.81.7.060.9024	4-SIP	PC Pin	1.5 V	33 V	60 VDC	DC	4-SIP	6 A	Through Hole	-20 C	70 °C	CE cURus EAC UKCA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 21.51

General part information

Solid State SPST-NO (1 Form A) 4-SIP
