GA400.A.305111

Active

TAOGLAS

WHIP ANTENNA, 5.15-5.925GHZ, 5.3DBI ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

TAOGLAS

WHIP ANTENNA, 5.15-5.925GHZ, 5.3DBI ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Specification	GA400.A.305111

Antenna Type	Module
Applications	LTE, 5G, Wi-Fi, 4G
Features	Cable
Features	3 m
Frequency (Center/Band)	752 MHz, 3.55 GHz, 892 MHz, 1.955 GHz, 657.5 MHz, 2.59 GHz, 1.4725 GHz, 450 MHz, 5.5375 GHz
Frequency Group	Wide Band
Height (Max) [Max]	16.5 mm
Height (Max) [Max]	0.65 "
Ingress Protection	IP67
Mounting Type	Adhesive
Number of Bands	9
Power - Max [Max]	2 W
RF Family/Standard	Cellular, WiFi

Part	Mounting Type	Frequency Group	Ingress Protection	Antenna Type	RF Family/Standard	Frequency (Center/Band)	Power - Max [Max]	Number of Bands	Height (Max) [Max]	Height (Max) [Max]	Applications	Features	Features
TAOGLAS GA400.A.305111	Adhesive	Wide Band	IP67	Module	Cellular WiFi	1.4725 GHz 1.955 GHz 2.59 GHz 3.55 GHz 5.5375 GHz 450 MHz 657.5 MHz 752 MHz 892 MHz	2 W	9	16.5 mm	0.65 "	4G 5G LTE Wi-Fi	Cable	3 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

RF ANTENNA 4G, 5G, LTE, Wi-Fi Module SMA Male Adhesive
