NINA-B222-02B
Obsoleteu-blox
RF TXRX MOD BLUETOOTH CHIP SMD
Deep-Dive with AI
Search across all available documentation for this part.
NINA-B222-02B
Obsoleteu-blox
RF TXRX MOD BLUETOOTH CHIP SMD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | NINA-B222-02B |
|---|---|
| Antenna Type | Integrated, Chip |
| Current - Receiving | 108 mA |
| Current - Transmitting | 147 mA |
| Data Rate | 3 Mbps |
| Frequency [Max] | 2.4835 GHz |
| Frequency [Min] | 2.4 GHz |
| Modulation | GFSK, 8DPSK, 4-QPSK |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 36-SMD Module |
| Power - Output | 11 dBm |
| Protocol | Bluetooth v4.2 + EDR |
| RF Family/Standard | Bluetooth |
| Sensitivity | -88 dBm |
| Serial Interfaces | UART, SPI, GPIO |
| Voltage - Supply [Max] | 3.6 V |
| Voltage - Supply [Min] | 3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
NINA-B222 Series
Bluetooth Bluetooth v4.2 + EDR Transceiver Module 2.4GHz ~ 2.4835GHz Integrated, Chip Surface Mount
Documents
Technical documentation and resources
No documents available
