TD-88162

Active

Macromatic Industrial Controls

RELAY TIME DEL 10230HR 10A 240V

Search across all available documentation for this part.

Active

Macromatic Industrial Controls

RELAY TIME DEL 10230HR 10A 240V

Technical Specifications

Parameters and characteristics for this part

Specification	TD-88162

Contact Rating @ Voltage	240 VAC, 30 VDC, 10 A
Delay Time [Max]	10230 Hrs
Delay Time [Min]	0.05 Sec
Function	Programmable (Multi-Function)
Mounting Type	Socketable
Relay Type	Mechanical Relay
Termination Style	Plug In, 8 Pin (Octal)
Timing Adjustment Method	DIP Switches
Timing Initiate Method	Input Voltage
Voltage - Supply	120 VAC

Part	Mounting Type	Timing Initiate Method	Contact Rating @ Voltage	Termination Style	Delay Time [Max]	Delay Time [Min]	Timing Adjustment Method	Relay Type	Function	Voltage - Supply
Macromatic Industrial Controls TD-88162	Socketable	Input Voltage	10 A 30 VDC 240 VAC	Plug In 8 Pin (Octal)	10230 Hrs	0.05 Sec	DIP Switches	Mechanical Relay	Programmable (Multi-Function)	120 VAC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 115.12

General part information

Programmable (Multi-Function) Time Delay Relay SPDT (1 Form C) 0.05 Sec ~ 10230 Hrs Delay 10A @ 240VAC/30VDC Socketable

Technical documentation and resources

No documents available
