NFZ5BBW450LZ10L

Unknown

Murata Power Solutions Inc.

FERRITE BEAD 45 OHM 2020 1LN

Search across all available documentation for this part.

Unknown

Murata Power Solutions Inc.

FERRITE BEAD 45 OHM 2020 1LN

Technical Specifications

Parameters and characteristics for this part

Part	Number of Lines	Height (Max) [Max]	Height (Max) [Max]	Mounting Type	Impedance @ Frequency	DC Resistance (DCR) (Max) [Max]	Ratings	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Package / Case	Current Rating (Max) [Max]
Murata Power Solutions Inc. NFZ5BBW520LZ10L	1	0.087 in	2.2 mm	Surface Mount	52 Ohms	120 mOhm	AEC-Q200	0.197 in	5 mm	0.197 "	5 mm	125 °C	-40 °C	2020	5050 Metric	1.61 A
Murata Power Solutions Inc. NFZ5BBW2R9LZ10L	1	0.087 in	2.2 mm	Surface Mount	2.9 Ohms	14 mOhm	AEC-Q200	0.197 in	5 mm	0.197 "	5 mm	125 °C	-40 °C	2020	5050 Metric	4 A
Murata Power Solutions Inc. NFZ5BBW970LN10L
Murata Power Solutions Inc. NFZ5BBW7R6LZ10L
Murata Power Solutions Inc. NFZ5BBW100LZ10L	1	0.087 in	2.2 mm	Surface Mount	10 Ohms	29 mOhm	AEC-Q200	0.197 in	5 mm	0.197 "	5 mm	125 °C	-40 °C	2020	5050 Metric	3 A
Murata Power Solutions Inc. NFZ5BBW450LZ10L	1	0.087 in	2.2 mm	Surface Mount	45 Ohms	100 mOhm	AEC-Q200	0.197 in	5 mm	0.197 "	5 mm	125 °C	-40 °C	2020	5050 Metric	1.65 A
Murata Power Solutions Inc. NFZ5BBW610LN10L	1	0.087 in	2.2 mm	Surface Mount	61 Ohms	127 mOhm		0.197 in	5 mm	0.197 "	5 mm	125 °C	-40 °C	2020	5050 Metric	1.6 A
Murata Power Solutions Inc. NFZ5BBW7R6LN10L	1	0.087 in	2.2 mm	Surface Mount	7.6 Ohms			0.197 in	5 mm	0.197 "	5 mm	125 °C	-40 °C	2020	5050 Metric	3.1 A
Murata Power Solutions Inc. NFZ5BBW220LN10L	1	0.087 in	2.2 mm	Surface Mount	22 Ohms	53 mOhm		0.197 in	5 mm	0.197 "	5 mm	125 °C	-40 °C	2020	5050 Metric	2.3 A
Murata Power Solutions Inc. NFZ5BBW970LZ10L

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Cut Tape (CT)	1	$ 0.50
	Digi-Reel®	1	$ 0.50
	Tape & Reel (TR)	500	$ 0.21

General part information

45 Ohms @ 1 MHz 1 Ferrite Bead 2020 (5050 Metric) 1.65A 100mOhm
